15 amp Blade Duo In Drawer Outlet

Name: 15 amp Blade Duo In Drawer Outlet
Brand: Docking Drawer
Price: 290.00 CAD
Availability: InStock

Rated 4.9 out of 5

Based on 128 reviews

$586.00 CAD

SKU: 1514-278W

Verify the Fit

Will it Fit in My Drawer?

Enter your drawer box measurements in inches

Width

Height

Depth

Cabinet Depth

Choose USB Charging Speed

Pick Configuration

Select Finish

ETL Listed for use in the US and Canada, our 15 amp Blade Duo in-drawer outlets are easy to install into any drawer. They’re designed with safety in mind, featuring tamper-resistant outlets and an interlocking thermostat that cuts power if surrounding temperatures exceed 120°F.

Transform your drawer with Blade Series Outlets

Enhance your drawer’s functionality with the advanced Blade Duo 15 amp In-Drawer Outlet by Docking Drawer. This modern solution delivers seamless in-drawer power and charging, combining safety, practicality, and smart design. From charging phones and tablets to powering hair tools or small kitchen appliances, Blade Duo outlets offer the most reliable and user-friendly in-drawer power option available.

Intelligent Power for Every Drawer

Blade Series outlets are engineered to fit virtually any drawer style and plug into a standard wall outlet using a 4.5-foot cord. Installation is straightforward, requiring just basic tools and seven included screws. With the Blade Duo, you can charge up to eight devices or power four at once, eliminating countertop clutter and keeping cords out of sight. The outlets are also upgradeable, allowing you to swap configurations as technology evolves—making them both repairable and future-ready.

Effortless Installation

Setting up the Blade Series is quick and hassle-free. Compatible with shallow, tall, narrow, and vertical drawers, these outlets can be oriented left, right, up, or down to match your needs. Only 2" of clearance is needed behind the drawer box—or 1.25" with a spacer for tighter spaces—so they fit into both custom and standard cabinetry. The 4.5-foot power cord plugs directly into any in-cabinet outlet, and all necessary screws are provided for a smooth installation process.

Built-In Safety You Can Trust

Docking Drawer outlets are ETL Listed for the US & Canada, feature tamper-resistant receptacles, and include an integrated safety mechanism that disconnects power if temperatures exceed 49°C. Each outlet undergoes extensive cycle testing—over 500,000 open/close cycles—to ensure long-term reliability. That’s why every Blade Series outlet is backed by a five-year warranty, giving you lasting peace of mind for your home and family.

Compliant w/Canadian Electrical Code

All USB-only configurations are CEC compliant as they come and and can remain energized when the drawer is closed to charge devices. If purchasing an AC configuration for applications such as powered vanity styling drawers or kitchen appliance pullouts, we recommend pairing it with our Blade Safety Outlet, which cuts power as the drawer begins to close and complies with the Canadian Electrical Code for high voltage outlets within the cabinet.

	Imperial	Metric
Outlet Width	13”	330mm
Outlet Height	4.64"	118mm
Outlet Depth	2.5"	64mm
Receptacle Box Depth	1.93"	49mm
Cover Plate Height	2.52"	64mm
Cover Plate Width	11.26"	286mm
Cover Plate Thickness	0.29"	7.5mm
Cable Management Arms Height	3"	76mm
Cord Length (15 amp) measured from the rear mounting bracket	54"	1.37m
Cord Length (20 amp) measured from the rear mounting bracket	36"	0.9m

#	Outlet Configuration	Outlet Specifications
1	(2) USB-A & (2) AC	AC: 15 amps @ 120 VAC USB-A: 3.6 amps @ 5 VDC
2	(4) USB-A	4.2 amps @ 5 VDC
3	(2) 30W USB-C & (2) AC	AC: 15 amps @ 120 VAC USB-C (single port connected to PD device): 3 amps @ 9 VDC (30W) USB-C (single port connected to non-PD device): 3 amps @ 5 VDC (15W) USB-C (both ports connected): 3 amps @ 5 VDC (30W total power)
4	(1) USB-C 30W, (1) USB-A & (2) AC	AC: 15 amps @ 120 VAC USB-C (non-PD device): 3 amps @ 5 VDC (15W) USB-A: 2.4 amps @ 5 VDC
5	(2) AC - GFCI	15 amps @ 120 VAC
6	(2) AC	15 amps @ 120 VAC
7	(2) 65W & (2) AC	AC: 15 amps @ 120 VAC USB-C (PD) 65 Watt Shared USB-C (single port connected to PD device): 65W 5V/3A; 9V/3A; 12V/3A; 15V/3A; 20V/3.25A USB-C (both ports connected to PD devices): 65W total C1/C2: 5V/3A; 9V/3A; 12V/2.5A; 15V/2A; 20V/1.5A
8	(2) 30W USB-C & (2) USB-A	USB-C (PD) 30 Watt Shared USB-C (single port connected to PD device): 30W max 5V/3A; 9V/3A; 12V/3A; 15V/3A; 15V/2A; 20V/1.5A USB-C (both ports connected): 15W each port C1:5V/3A C2:5V/3A USB-A (max with one or both ports connected) 12W total 5v/2.4A

Spec Books

Tear Sheets

Installation Manuals

DXF & Step Files

Literature

Mounting Diagrams

Installation Videos

Electrical Certifications

How to Prepare for Your Docking Drawer Installation

To get started with any Docking Drawer Blade Series project, first determine your drawer box style. There are four main types: Shallow, Tall, Narrow, and Vertical. Once you’ve identified the type, measure the outside width of your drawer box to ensure it meets the minimum size requirements for a Blade Series outlet. You can find the specific minimum dimensions here.

Planning Your Project in Canada

Docking Drawer outlets are ETL Listed for use in Canada. When planning your installation, follow the steps above and keep these Canadian Electrical Code (CEC) guidelines in mind:

USB-Only In-Drawer Charging for Canada: Choose a Docking Drawer Blade Duo (1514-288) or Blade (1514-180) model with USB-C and/or USB-A ports. Since USB ports are low voltage, these outlets can safely remain powered and charge your devices even when the drawer is closed.
AC In-Drawer Outlets for Canada: For 15-20 amp Blade Duo or Blade outlets with AC power, we recommend pairing them with our Blade Safety Outlet for CEC compliance. The Blade Safety Outlet will automatically cut power to the in-drawer outlet as the drawer closes, making it compliant for use in areas like bathroom styling drawers, kitchen appliance pullouts and other high voltage in-drawer power applications.

Note: The final decision on code compliance always rests with your local Authorities Having Jurisdiction (AHJ).

Do I need a 15 or 20 amp Docking Drawer Blade Series Outlet?

We often get asked this question when choosing the right outlet for your drawer, especially in bathroom vanity projects where the outlet is used to power hair dryers and curling irons. See the answer here.

How do I ensure my Blade Series outlet is GFCI protected?

If a Blade Series outlet is installed in a location that requires GFCI, there are 4 ways to install Blade Series outlets to have GFCI Properties. See the 4 ways here.
